Long Arm Extra Heavy Duty Compound Feed Flat Bed Lock Stitch Sewing Machine GA204-420

GA204 series sewing machine is widely used and knowing in extra heavy duty field, with extra big shuttle hook, flat bed lockstitch.

CONTACT NOW PDF DOWNLOAD

Product Detail

Product Tags

GA204 series sewing machine is widely used and knowing in extra heavy duty field, with extra big shuttle hook, flat bed lockstitch. This model are mostly used for upholstery, leather sewing, also some special field for very thick threads and very thick hard material sewing. GA204-420 is long arm type GA204-370, arm long 420mm, have a better performance for big size material sewing. With same structure of Adler machine, have better penetration of hard material. Widely used for sewing webbing slings, safety harness, and leather products.

With different arm long GA204 have different types:

GA204-370 arm long 310mm

GA204-420 arm long 420mm

GA204-762 arm long 762mm

Specification:

Model No.	GA204-370	GA204-420	GA204-762
Max Working Speed	800 RPM.	800 RPM.	800 RPM.
Stitch Length	12 MM	12 MM	12 MM
Presser foot lift	15/20MM	15/20MM	15/20MM
Working Area	310X185 MM	420X185 MM	762X185 MM
Needle	DYX3	DYX3	DYX3

Application:

Labor protection products. Lifting slings, rigging slings, safety harnesses, fall protection equipment, climbing gear, parachutes, backpacks straps, saddle materials, sails, carpets, thick canvas & leather, bags, rugs, safety belts, etc.

Thick thread decorative top stitching on leather sofas and arm chairs, automotive upholstery, car seat covers etc.
